The magic of clGetKernelWorkGroupInfo

Workgroup with unknown characteristics
Workgroup with unknown characteristics

It’s not easy to get the available private memory size – actually it’s impossible to get this information directly from the device/drivers, using the OpenCL API. This can only be explained after you dive deep into clGetKernelWorkGroupInfo – the function that tells you how well your kernel fits on the device. It is strange this function is not often discussed.

Memory sizes

CL_KERNEL_LOCAL_MEM_SIZE

Returns the amount of local memory, in bytes, being used by a kernel (per work-group). Use CL_DEVICE_LOCAL_MEM_SIZE to find out the maximum.

CL_KERNEL_PRIVATE_MEM_SIZE

Returns the minimum amount of private memory, in bytes, used by each work-item in the kernel.

Work sizes

CL_KERNEL_GLOBAL_WORK_SIZE

This answers the question “What is the maximum value for global_work_size argument that can be given to clEnqueueNDRangeKernel?”. The result is of type size_t[3].

CL_KERNEL_WORK_GROUP_SIZE

The is the same for local_work_size. The kernel’s resource requirements (register usage etc.) are used, to determine what this work-group size should be.

CL_KERNEL_COMPILE_WORK_GROUP_SIZE

If __attribute__((reqd_work_group_size(X, Y, Z))) is used, then (X, Y, Z) is returned, else (0, 0, 0).

CL_KERNEL_PREFERRED_WORK_GROUP_SIZE_MULTIPLE

It returns a performance-hint: if the total number of work-items is a multiple of this number, then you’ll get good results. So no more remembering 32 or 64 for specific GPUs, but simply kick in a call to this function.

Combined with clDeviceInfo’s CL_DEVICE_MAX_WORK_ITEM_DIMENSIONS, you can fine-tune your workgroup-size in case you need the group-size to be as large as possible.

Read more?

You’ll find interesting usages when specifically looking for the flags on Github or Stackoverflow.

Short list of interesting Stackoverflow discussions:
