GPU and FPGA challenge for MSc and PhD students

While going through my email, I found out about the third “HiPEAC Student Heterogeneous Programming Challenge”. Unfortunately the deadline was last week, but just got an email: if you register by this weekend (17 September), you can still join.

EDIT: if you joined, be sure to comment in early November how it was. This would hopefully motivate others to join in next year. Continue reading “GPU and FPGA challenge for MSc and PhD students”

The single-core, multi-core and many-core CPU

Multi-core CPU from 2011

CPUs are now split up in 3 types, depending on the number of cores: single (1), multi (2-8) and many (10+).

I find it more important now to split up into these three types, as the types of problems to be solved by each is very different. Based on the problem-differences I’m even expecting that the number of cores between multi-core CPUs and many-core CPUs will grow.

Below are the three types of CPUs discussed and a small discussion on many-core processors we see around. Continue reading “The single-core, multi-core and many-core CPU”

HPC centre EPCC says: “Better software, better science”

The University of Edinburgh houses the HPC centre EPCC. Neelofer Banglawala wrote about a programme which funds the development and improvement of scientific software, and also discussed about the results.

Many of the 10 most used application codes on ARCHER have been the focus of an eCSE project. Software with more modest user bases have improved user uptake and widened their impact through eCSE-funded work. Furthermore, performance improvements can lead to tens of thousands of pounds of savings in compute time.

Saving tens of thousands of pounds is certainly worth the investment. This also means more users can work on the same supercomputer, thus reducing waiting times. Continue reading “HPC centre EPCC says: “Better software, better science””

Demo: cartoonizer on an Altera Arria 10 FPGA

It takes quite some effort to program FPGAs using VHDL or Verilog. Since several years Intel/Altera has OpenCL-drivers, with the goal to reduce this effort. OpenCL-on-FPGAs reduced the required effort to a quarter of the time, while also making it easier to alter the specifications during the project. Exactly the latter was very beneficiary when creating the demo, as the to-be-solved problem was vaguely defined. The goal was to make a video look like a cartoon using image filters. We soon found out that “cartoonized” is a vague description, and it took several iterations to get the right balance between blur, color-reduction and edge-detection. Continue reading “Demo: cartoonizer on an Altera Arria 10 FPGA”

CPU Code modernisation – our hidden expertise

You’ve seen the speedups possible on GPUs. We secretly know that many of these techniques would also work on modern multi-core CPUs. If after the first optimisations the GPU still gets an 8x speedup, the GPU is the obvious choice. When it’s 2x, would the better choice be a bigger CPU or a bigger GPU? Currently the GPU is chosen more often.

Now AMD, Intel and AMD have 28+ core CPUs, the answer to that question might now lean towards the CPU. With a CPU that has 32 cores and 256bit vector-computations via AVX2, each clock-cycle 32 double4 can be computed. A 16-core AVX1 CPU could work on 16 double2’s, which is only a fourth of that performance. Actual performance compared to peak-performance is comparable to GPUs here. Continue reading “CPU Code modernisation – our hidden expertise”

New training dates for OpenCL on CPUs and GPUs!

OpenCL remains to be a popular programming language for accelerators, from embedded to HPC. Good examples are consumer software and embedded devices. With Vulkan potentially getting OpenCL-support in the future, the supported devices will only increase.

For multicore-CPUs and GPUs we now have monthly training dates for the rest of the year:

Minimum number of participants is two. By request the location and date can be changed.

The first day of the training is the OpenCL Foundations training, which can be booked separately.

For more information call us at +31854865760.

IWOCL 2017 slides and proceedings now available

A month ago IWOCL (OpenCL workshop) and DHPCC++ (C++ for GPUs) took place. Meanwhile many slides and posters have been published online. As of today 23 talks are with slides.

The proceedings are available via the ACM Digital Library. This needs a ACM Digital Library subscription of $198, if your company/university does not have access yet.

IWOCL 2018 will be in Edinburgh (Scotland, UK), 15-17 May 2018 (provisional).

Bug fixing the MESA 3D drivers

Most of our projects are around performance optimisation, but we’re cleaning up bugs too. This is because you can only speed up software when certain types of bugs are cleared out. A few months ago, we got a different type of request. If we could solve bugs in MESA 3D that appear in games.

Yes, we wanted to try that and got a list of bugs to solve. And as you can read, we were successful.

Below you found a detailed description of one of the 5 bugs we solved by digging deep into the different games and the MESA 3D drivers. At the end of the blog post you’ll find the full list with links to issues in MESA’s bugtracker. Continue reading “Bug fixing the MESA 3D drivers”

Slow Software Hotline

In the perfect world all software is fast, giving us time to do actual work. Unfortunately we live in an unperfect world, and we have to spend extra time controlling our anger as the software keeps us waiting.

Therefore we have opened the Slow Software Hotline – reachable via both phone and email. It has one goal: make you feel happy again.

Reporting is easy. Just name the commercial software that needs to be sped up and why. We’ll do the rest. If you need help with initial anger management due to the slow (and/or buggy) software, we’re happy to help with breathing practises.

Phone: +31 854865760


We will not sit still until all software is fast. Speeding up all software out there. One at the time.

Why did AMD open source ROCm’s OpenCL driver-stack?

AMD open sourced the OpenCL driver stack for ROCm in the beginning of May. With this they kept their promise to open source (almost) everything. The hcc compiler was open sourced earlier, just like the kernel-driver and several other parts.

Why this is a big thing?
There are indeed several open source OpenCL implementations, but with one big difference: they’re secondary to the official compiler/driver. So implementations like PortableCL and Intel Beignet play catch-up. AMD’s open source implementations are primary.

It contains:

  • OpenCL 1.2 compatible language runtime and compiler
  • OpenCL 2.0 compatible kernel language support with OpenCL 1.2 compatible runtime
  • Support for offline compilation right now – in-process/in-memory JIT compilation is to be added.

For testing the implementation, see Khronos OpenCL CTS framework or Phoronix

Why is it open sourced?

There are several reasons. AMD wants to stand out in HPC and therefore listened carefully to their customers, while taking good note on where HPC was going. Where open source used to be something not for businesses, it is now simply required to be commercially successful. Below are the most important answers to this question.

Give deeper understanding of how functions are implemented

It is very useful to understand how functions are implemented. For instance the difference between sin() and native_sin() can tell you a lot more on what’s best to use. It does not tell how the functions are implemented on the GPU, but does tell which GPU-functions are called.

Learning a new platform has never been so easy. Deep understanding is needed if you want to go beyond “it works”.

Debug software

When you are working on a large project and have to work with proprietary libraries, this is a typical delay factor. I think every software engineer has this experience that the library does not perform as was documented and work-arounds had to be created. Depending on the project and the library, it could take weeks of delay – only sarcasm can describe these situations, as the legal documents were often a lot better than the software documents. When the library was open source, the debugger could step in and give the “aha” that was needed to progress.

When working with drivers it’s about the same. GPU drivers and compilers are extremely complex and ofcourse your project hits that bug which nobody encountered before. Now all is open source, you can now step into the driver with the debugger. Moreover, the driver can be compiled with a fix instead of work-around.

Get bugs solved quicker

A trace now now include the driver-stack and the line-numbers. Even a suggestion for a fix can be given. This not only improves reproducibility, but reduces the time to get the fix for all steps. When a fix is suggested AMD only needs to test for regression to accept it. This makes the work for tools like CLsmith a lot easier.

Have “unimportant” specific improvements done

Say your software is important and in the spotlight, like Blender or the LuxMark benchmark, then you can expect your software gets attention in optimisations. For the rest of us, we have to hope our special code-constructions are alike one that is targeted. This results in many forums-comments and bug-reports being written, for which the compiler team does not have enough time. This is frustrating for both sides.

Now everybody can have their improvements submitted, giving it does not slow down the focus software ofcourse.

Get the feature set extended

Adding SPIR-V is easy now. The SPIRV-frontend needs to be added to ROCm and the right functions need to be added to the OpenCL driver. Unfortunately there is no support for OpenCL 2.x host-code yet – I understood by lack of demand.

For such extensions the AMD team needs to be consulted first, because this has implications on the test-suite.

Get support for complete new things

It takes a single person to make something completely new – this becomes a whole easier now.

More often there is opportunity in what is not there yet, and research needs to be done to break the chicken-egg. Optimised 128 bit computing? Easy complex numbers in OpenCL? Native support for Halide as an alternative to OpenCL? All high performance code is there for you.

Initiate alternative implementations (?)

Not a goal, but forks are coming for sure. For most forks the goals would be like the ones above, to later be merged with the master branch. There are a few forks that go their own direction – for now hard to predict where those will go.

Improve and increase university collaborations

If the software was protected, it was only possible under strict contracts to work on AMD’s compiler infrastructure. In the end it was easier to focus on the open source backends of LLVM than to go through the legal path.

Universities are very important to find unexpected opportunities, integrate the latest research in, bring potential new employees and do research collaborations. Added bonus for the students is that the GPUs might be allowed to used for games too.

Timour Paltashev (Senior manager, Radeon Technology Group, GPU architecture and global academic connections) can be reached via timour dot paltashev at amd dot com for more info.

Get better support in more Linux distributions

It’s easier to include open source drivers in Linux distributions. These OpenCL drivers do need a binary firmware (which were disassembled and seem to do as advertised), but the discussion is if this is part of the hardware or software to mark it as “libre”.

There are many obstacles to have ROCm complete stack included as the default, but with the current state it makes much more chance.


Phoronix has done some benchmarks on ROCm 1.4 OpenCL in January on several systems and now ROCm 1.5 OpenCL on a Radeon RX 470. Though the 1.5 benchmarks were more limited, the important conclusion is that the young compiler is now mostly on par with the closed source OpenCL implementation combined with the AMDGPU-drivers. Only Luxmark AMDGPU was (much) better. Same comparison for the old proprietary fgrlx drivers, which was fully optimised and the first goal to get even with. You’ll see that there will be another big step forward with ROCm 1.6 OpenCL.

Get started

You can find the build instructions here. Let us know in the comments what you’re going to do with it!

Khronos Releases OpenCL 2.2 With SPIR-V 1.2

Today Khronos has released OpenCL 2.2 with SPIR-V 1.2.

The most important changes are:

  • A static subset of the C++14 standard as a kernel language. The OpenCL C++ kernel language includes classes, templates, lambda expressions, function overloads and many other constructs to increase parallel programming productivity through generic and meta-programming.
  • Access to the C++ language from OpenCL library functions to provide increased safety and reduced undefined behavior while accessing features such as atomics, iterators, images, samplers, pipes, and device queue built-in types and address spaces.
  • Pipe storage, which are compile time pipes. It’s a device-side type in OpenCL 2.2 that is useful for FPGA implementations to enable efficient device-scope communication between kernels.
  • Enhanced optimization of generated SPIR-V code. Applications can provide the value of specialization constants at SPIR-V compilation time, a new query can detect non-trivial constructors and destructors of program scope global objects, and user callbacks can be set at program release time.
  • KhronosGroup/OpenCL-Headers repository has been flattened. From now on, all version of OpenCL headers will be available not at separate branches, but all in master branch in separate directories named opencl10, opencl11 etc. Old branches are not removed, but they may not be updated in the future.
  • OpenCL specifications are now open source. OpenCL Working Group decided to publish sources of recent OpenCL specifications on GitHub, including just released OpenCL 2.2 and OpenCL C++ specifications. If you find any mistake, you can create an appropriate merge request fixing that problem.

This is what we said about the release:

“We are very excited and happy to see OpenCL C++ kernel language being a part of the OpenCL standard,” said Vincent Hindriksen, founder and managing director of StreamHPC. “It’s a great achievement, and it shows that OpenCL keeps progressing. After developing conformance tests for OpenCL 2.2 and helping finalizing OpenCL C++ specification, we are looking forward to work on first projects with OpenCL 2.2 and the new kernel language. My team believes that using OpenCL C++ instead of OpenCL C will result in improved software quality, reduced maintenance effort and faster time to market. We expect SPIR-V to heavily impact the compiler ecosystem and bring several new OpenCL kernel languages.”

Continue reading “Khronos Releases OpenCL 2.2 With SPIR-V 1.2”

Caffe and Torch7 ported to AMD GPUs, MXnet WIP

Last week AMD released ports of Caffe, Torch and (work-in-progress) MXnet, so these frameworks now work on AMD GPUs. With the Radeon MI6, MI8 MI25 (25 TFLOPS half precision) to be released soonish, it’s ofcourse simply needed to have software run on these high end GPUs.

The ports have been announced in December. You see the MI25 is about 1.45x faster then the Titan XP. With the release of three frameworks, current GPUs can now be benchmarked and compared.

Especially the expected good performance/price ratio will make this very interesting, especially on large installations. Another slide discussed which frameworks will be ported: Caffe, TensorFlow, Torch7, MxNet, CNTK, Chainer and Theano.

This leaves HIP-ports of TensorFlow, CNTK, Chainer and Theano still be released. Continue reading “Caffe and Torch7 ported to AMD GPUs, MXnet WIP”

Rebranding the company name from StreamComputing to StreamHPC

Since 2010 the name StreamComputing has been used and is widely known now in the GPU-computing industry. But the name has three problems: we don’t have the .com domain, it does not directly show what we do, and the name is quite long.

Some background on the old domain name

While the initial focus was Europe, for years our projects are done for 95% for customers outside the Netherlands and over 50% outside Europe – with the .eu domain we don’t show our current international focus.

But that’s not all. The name sticks well in academics, as they’re more used to have longer names – just try to read a book on chemistry. Names I tested as alternatives were not well-received for various reasons. Just like “fast” is associated with fast food, computing is not directly associated with HPC. So fast computing gets simply weird. Since several customers referred to us as Stream, it made much sense to keep that part of the name.

Not a new begin, but a more focused continuation

Stream HPC defines more what we are: we build HPC software. Stream HPC combines the well-known name combined with our diverse specialization.

  • Programming GPUs with CUDA or OpenCL.
  • Scaling code to multiple CPU and GPUs
  • Creating AI-based software
  • Speeding up code and optimizing for given architectures
  • Code improvement
  • Compiler tests and compiler building (LLVM)

With the HPC-focus we were more able to improve ourselves. We have put a lot of time in professionalizing our development-environment and project-management by implementing suggestions from current customers and our friends. We were already used to work fully independent and be self-managed, but now we were able to standardize more of it.

The rebranding process

Rebranding will take some time, as our logo and name is in many places. For the legal part we will take some more time, as we don’t want to get into problems with i.e. all the NDAs. Email will keep working on both domains.

We will contact all organizations we’re a member of over the coming weeks. You can also contact us, if you read this.

StreamComputing will never really go away. The name was with us for 7 years and stands for growing with the upcoming of GPU-computing.

What is Khronos as of today?

The Khronos Group is the organization behind APIs like OpenGL, Vulkan and OpenCL. Over one hundred companies are a member and decide together what your next year phone, camera, computer or media device will be capable of.

We’re at the right, near the bottom.

We work most with OpenCL, but you probably noticed we work with OpenGL, Vulkan and SPIR too. Currently they have the following APIs:

  • COLLADA, a file-format intended to facilitate interchange of 3D assets
  • EGL, an interface between Khronos rendering APIs such as OpenGL ES or OpenVG and the underlying native platform window system
  • glTF, a file format specification for 3D scenes and models
  • OpenCL, a cross-platform computation API.
  • OpenGL, a cross-platform computer graphics API
  • OpenGL ES, a derivative of OpenGL for use on mobile and embedded systems, such as cell phones, portable gaming devices, and more
  • OpenGL SC, a safety critical profile of OpenGL ES designed to meet the needs of the safety-critical market
  • OpenKCam, Advanced Camera Control API
  • OpenKODE, an API for providing abstracted, portable access to operating system resources such as file systems, networks and math libraries
  • OpenMAX, a layered set of three programming interfaces of various abstraction levels, providing access to multimedia functionality
  • OpenML, an API for capturing, transporting, processing, displaying, and synchronizing digital media
  • OpenSL ES, an audio API tuned for embedded systems, standardizing access to features such as 3D positional audio and MIDI playback
  • OpenVG, an API for accelerating processing of 2D vector graphics
  • OpenVX, Hardware acceleration API for Computer Vision applications and libraries
  • OpenWF, APIs for 2D graphics composition and display control
  • OpenXR, an open and royalty-free standard for virtual reality and augmented reality applications and devices
  • SPIR, a intermediate compiler target for OpenCL and Vulkan
  • StreamInput, an API for consistently handling input devices
  • Vulkan, a low-overhead computer graphics API
  • WebCL, a JavaScript binding to OpenCL within a browser
  • WebGL, a JavaScript binding to OpenGL ES within a browser on any platform supporting the OpenGL or OpenGL ES graphics standards

Too few people understand that the organization is very unique, as the biggest processor vendors are discussing collaborations and how to move the market, while they’re normally the fiercest competitors. Without Khronos it would have been a totally different world.

AMD ROCm 1.5 Linux driver-stack is out

ROCm is AMD’s open source Linux-driver that brings compute to HSA-hardware. It does not provide graphics and therefore focuses on monitor-less applications like machine learning, math, media processing, machine vision, large scale simulations and more.

For those who do not know HSA, the Heterogeneous Software Architecture defines hardware and software such that different processor types (like CPU, GPU, DSP and FPGA) can seamlessly work together and have fine-grained memory sharing. Read more on HSA here.

About ROCm and it’s short history

The driver stack has been on Github for more than a year now. Development is done internally, while communication with users is done mostly via Gitlab’s issue tracker. ROCm 1.0 was publicly announced on 25 April 2016. After version 1.0, there now have been 6 releases in only one year – the 4 months of waiting time between 1.4 and 1.5 was therefore relatively long. You can certainly say the development is done at a high pace.

ROCm 1.4 was released end of December and besides a long list of fixed bugs, it had the developer preview of OpenCL 2.0 kernel support added. Support for OpenCL was limited to Fiji (R9 Fury series) and Baffin/Ellesmere (Radeon RX 400 series) GPUs, as these have the best HSA support of current GPU offerings.

Currently not all parts of the driver stack is open source, but the binary blobs will be open sourced eventually. You might think why a big corporation like AMD would open source such important part of their offering. This makes totally sense if you understand that their most important customers spend a lot of time on making the drivers and their code work together. By giving access to the code, debugging becomes a lot easier and will reduce development time. This will result in less bugs and a shorter time-to-market for the AMD-version of the software.

The OpenCL language runtime and compiler will be open sourced soon, so AMD offers full OpenCL without any binary blob.

What does ROCm 1.5 bring?

Version 1.5 adds improved support for OpenCL, where 1.4 only gave a developer preview. Both feature-support and performance have been improved. Just like in 1.4 there is support for OpenCL 2.0 kernels and OpenCL 1.2 host-code – the tool clinfo mentions there is even some support of 2.1 kernels, but we haven’t fully tested this yet.

The command-line based administration (ROCm-SMI) adds power monitoring, so power-efficiency can be measured.
The HCC compiler was upgraded to the latest CLANG/LLVM. There also have been big improvement in C++ compatibility.

Other improvements:

  1. Added new API hipHccModuleLaunchKernel which works exactly as hipModuleLaunchKernel but takes OpenCL programming models launch parameters. And its test
  2. Added new API hipMemPtrGetInfo
  3. Added new field to hipDeviceProp_t -> gcnArch which returns 803, 700, 900, etc.,

Bug fixes:

  1. Fixed Copyright and header names
  2. Fixed issue with bit_extract sample
  3. Enabled lgamma and lgammaf
  4. Added guard for GFX8 specific intrinsics
  5. Fixed few issues with operator overloading of vector data types
  6. Fixed atanf
  7. Added guard for __half data types to work with clang version more than 3. (Will be removed eventually).
  8. Fixed 4_shfl to work only for gfx803 as hawaii don’t support permute ops

Current hardware support:

  • GFX7: Radeon R9 290 4 GB, Radeon R9 290X 8 GB, Radeon R9 390 8 GB, Radeon R9 390X 8 GB, FirePro W9100 (16GB), FirePro S9150 (16 GB), and FirePro S9170 (32 GB).
  • GFX8: Radeon RX 480, Radeon RX 470, Radeon RX 460, Radeon R9 Nano, Radeon R9 Fury, Radeon R9 Fury X, Radeon Pro WX7100, Radeon Pro WX5100, Radeon Pro WX4100, and FirePro S9300 x2.

If you’re buying new hardware, pick a GPU from the GFX8 list. FirePro S9300 X2 is currently the server-grade solution of choice.

Keep an eye on the Phoronix website, which is usually first with benchmarking AMD’s open source drivers.

Install ROCm 1.5

Where 1.4 had support for Ubuntu 14.04, Ubuntu 16.04 and Fedora 23, 1.5 added support for Fedora 24 and dropped support for Ubuntu 14.04 and Fedora 23. On other distributions than Ubuntu 16.04 or Fedora 24 it *could* work, but there are zero guarantees.

Follow the instructions on Github step-by-step to get it installed via deb or rpm. Be sure to uninstall any previous release of ROCm to avoid problems.

The part on Grub might not be clear. For this release the magic GRUB_DEFAULT line on Ubuntu 16.04 is:

GRUB_DEFAULT="Advanced options for Ubuntu>Ubuntu, with Linux 4.9.0-kfd-compute-rocm-rel-1.5-76"

You need to alter this line with every update, else it’ll keep using the old version.

Make sure “/opt/rocm/bin/” is in your PATH when wanting to do some coding. When running the test, you should get:

/opt/rocm/hsa/sample$ sudo make
gcc -c -I/opt/rocm/include -o vector_copy.o vector_copy.c -std=c99
gcc -Wl,--unresolved-symbols=ignore-in-shared-libs vector_copy.o -L/opt/rocm/lib -lhsa-runtime64 -o vector_copy
/opt/rocm/hsa/sample$ ./vector_copy
Initializing the hsa runtime succeeded.
Checking finalizer 1.0 extension support succeeded.
Generating function table for finalizer succeeded.
Getting a gpu agent succeeded.
Querying the agent name succeeded.
The agent name is gfx803.
Querying the agent maximum queue size succeeded.
The maximum queue size is 131072.
Creating the queue succeeded.
"Obtaining machine model" succeeded.
"Getting agent profile" succeeded.
Create the program succeeded.
Adding the brig module to the program succeeded.
Query the agents isa succeeded.
Finalizing the program succeeded.
Destroying the program succeeded.
Create the executable succeeded.
Loading the code object succeeded.
Freeze the executable succeeded.
Extract the symbol from the executable succeeded.
Extracting the symbol from the executable succeeded.
Extracting the kernarg segment size from the executable succeeded.
Extracting the group segment size from the executable succeeded.
Extracting the private segment from the executable succeeded.
Creating a HSA signal succeeded.
Finding a fine grained memory region succeeded.
Allocating argument memory for input parameter succeeded.
Allocating argument memory for output parameter succeeded.
Finding a kernarg memory region succeeded.
Allocating kernel argument memory buffer succeeded.
Dispatching the kernel succeeded.
Passed validation.
Freeing kernel argument memory buffer succeeded.
Destroying the signal succeeded.
Destroying the executable succeeded.
Destroying the code object succeeded.
Destroying the queue succeeded.
Freeing in argument memory buffer succeeded.
Freeing out argument memory buffer succeeded.
Shutting down the runtime succeeded.

Also clinfo (installed from the default repo) should work.

Got it installed and tried your code? Did you see improvements? Share your experiences in the comments!

Not really ROCk-music, but this blog has been written while listening to the latest album of the Gorillaz

DHPCC++ Program known

During IWOCL a workshop takes place that discusses the opportunities that C++ brings to OpenCL-enabled processors. A well-know example is SYCL, but various other approaches are talked about.

The Distributed & Heterogeneous Programming in C/C++ Workshop just released their program:

  • HiHAT: A New Way Forward for Hierarchical Heterogeneous Asynchronous Tasking.
  • SYCL C++17 and OpenCL interoperability experimentation with triSYCL.
  • KART – A Runtime Compilation Library for Improving HPC Application Performance.
  • Using SYCL as an Implementation Framework for HPX Compute.
  • Adding OpenCL to Eigen with SYCL.
  • SYCL-BLAS: Leveraging Expression Trees for Linear Algebra.
  • Supporting Distributed and Heterogeneous Programming Models in ISO C++.
  • Towards an Asynchronous Data Flow Model for SYCL 2.2.
  • Communicating Execution Contexts using Channels.
  • Towards a Unified Interface for Data Movement.
  • Panel: What do you want in C++ for Heterogeneous.

As C++ is an important direction for OpenCL, we expect to see most of the discussions on programmability of OpenCL-enabled processors be done here.

The detailed program is to be released soon. For more information see the DHPCC++ webpage. At the IWOCL website you can buy tickets and passes – combining with IWOCL gives a discount.

IWOCL 2017 – all the talks

An overview of all the tutorials and talks for easy reading.

You can also download the PDF.

Heterogeneous Computing Using Modern C++ with OpenCL Devices – Rod Burns and Ruyman Reyes (Codeplay)

This hands-on session will provide an opportunity to get experience with SYCL using ComputeCpp™ Community Edition, a free to use implementation of the SYCL 1.2 standard. Attendees will be shown how to set up ComputeCpp and use it to write their own SYCL code to run on supported GPUs and CPUs.

SYCL is already able to dispatch to heterogeneous devices and it implements C++17 ParallelSTL, augmenting it with ability to dispatch to GPUs in addition to CPUs. This tutorial will demonstrate how to write parallel SYCL code and how to use the Khronos Group’s experimental Parallel STL implementation. The course outline is as follows

  • Start with a basic SYCL program that shows how to submit queues in a single task and stream-like object, comparing CPU, SYCL and OpenCL versions
  • Demonstrate how to access data across host and GPUs using buffers and accessors, the importance of life-time, and basic parallel constructs

Attendees are expected to have programming experience with C++ and a laptop either running Linux or having a VM manager installed such as VirtualBox. The required software will be provided on USB-sticks. This course is suitable for beginners, but is focused on intermediate to advanced parallel programming using C++.

Harnessing the Power of FPGAs with the Intel FPGA SDK for OpenCL- Byron Sinclair, Andrew Ling and Genady Paikin (Intel)

In this tutorial, we will introduce you to the reconfigurable hardware architecture and programming of Field Programmable Gate Arrays (FPGAs).

You will learn why FPGAs have become so popular in recent years, and understand the many advantages of using FPGAs in your HPC application. In particular, we will cover architectural features of FPGAs that make them well suited to many complex operations, including matrix multiplications and convolutions. In addition, we will introduce you to programming FPGAs using the Intel® FPGA SDK for OpenCL, and how specific OpenCL coding techniques can lead to efficient circuits implemented on the FPGA.

Finally, we will go over several case studies where FPGAs have shown very competitive performance when programmed using OpenCL, including convolutional neural nets, FFTs, and astronomy de-dispersion algorithms.

Unlock Intel GPUs for High Performance Compute, Media and Computer Vision Capabilities with Intel OpenCL Extensions – Jeff Mcallister, Biju George, Adam Herr and Ben Ashbaugh (Intel)

The keys to unlock the full performance potential of Intel GPUs for emerging workloads in general compute, media, computer vision, and machine learning are in the rich suite of Intel OpenCL extensions. These give developers direct access to unique Intel hardware capabilities, which until now have been difficult to master.
This tutorial builds step by step with multiple examples, including:

  • How to write high performance general compute applications based on the core concept of OpenCL subgroups.
  • How to use additional subgroup operations described in the Intel subgroups and media block read/write extensions.
  • Then using the framework of subgroups, we explain the device-side motion estimation extension which leverages the unique Intel GPU media sampler to accelerate motion estimation operations from OpenCL kernels.
  • Finally we explain the Video Enhancement (VEBOX) extension, which is an OpenCL host level API extension to leverage a powerful media fixed function unit to accelerate many frame level video enchancement operations.

Faster, smarter computer vision with AI and OpenCL – Uri Levy and Jeffrey Mcallister (Intel)

Learn how to use Intel machine learning and computer vision tools to get from concept to market faster for machine learning applications based on OpenCL and OpenVX. Build two example scenarios: autonomous driving with FPGA inference and a smart camera app using Intel Graphics inference. This presentation will show how a unified set of tools can reduce the complexity of developing heterogeneous machine learning apps – from training a model with input images, to creating a custom classifier, to building an optimized traditional computer vision pipeline around the classifier to create a full computer vision application

GPGPU Acceleration using OpenCL for a Spotlight SAR Simulator – Eric Balster, Jon Skeans and David Fan (University of Dayton) Marc Hoffman (US Air Force Research Laboratory)

In this paper, OpenCL is used to target a general purpose graphics processing unit (GPGPU) for acceleration of 2 modules used in a synthetic aperture radar (SAR) simulator. Two of the most computationally complex modules, the Generate Return and Back Projection modules, are targeted to an AMD FirePro M5100 GPGPU. The resulting speedup is 2.5X over multi-threaded C++ implementations of those algorithms running on an 8-core Intel I7 2.8GHz processor, 5X over singlethreaded C++ implementations, and 24X over native MATLAB implementations, on average.

Near Real-Time Risk Simulation of Complex Portfolios on Heterogeneous Computing Systems with OpenCL – Javier Alejandro Varela and Norbert Wehn (University of Kaiserslautern)

In this work, we exploit OpenCL to efficiently map the nested simulation of complex portfolios with multiple algorithms on heterogeneous computing systems. Code portability and customizations allow us to profile the kernels on different accelerating platforms, such as CPU, Intel’s Xeon Phi and GPU. The combination of OpenCL, a new bit-accurate algorithmic optimization and the extension of an existing numerical interpolation scheme allows us to achieve 1000x speedup compared to the state-of-the-art approach. Our system design minimizes costly host-device transfers and global memory, enabling complex portfolios to be easily scaled.

A Performance and Energy Evaluation of OpenCL-accelerated Molecular Docking – Leonardo Solis Vasquez and Andreas Koch (Technische Universität Darmstadt)

This work presents an OpenCL implementation of AutoDock, and a corresponding performance evaluation on two different platforms based on multi-core CPU and GPU accelerators. It shows that OpenCL allows highly efficient docking simulations, achieving speedups of ∼4x and ∼56x over the original serial AutoDock version, as well as energy efficiency gains of ∼2x and ∼6x. respectively. To the best of our knowledge, this work is the first one also considering the energy efficiency of molecular docking programs.

Assessing the feasibility of OpenCL CPU implementations for agent-based simulations – Nuno Fachada and Agostinho Rosa (Instituto Superior Técnico, Portugal)

In this paper we evaluate the feasibility of using CPU-oriented OpenCL for high-performance simulations of agent-based models. We compare a CPU-oriented OpenCL implementation of a reference ABM against a parallel Java version of the same model. We show that there are considerable gains in using CPU-based OpenCL for developing and implementing ABMs, with speedups up to 10x over the parallel Java version on a 10-core hyper-threaded CPU.

Enabling FPGAs as a True Device in the OpenCL Standard – Vincent Mirian and Paul Chow (University Of Toronto)

As FPGA capacities continue to increase, the ability to partition and partially reconfigure the FPGA will become even more desirable. The fundamental issue is how FPGAs are currently viewed as devices in the OpenCL model. In this paper, we propose a small change to the OpenCL definition of a device that unlocks the full potential of FPGAs to the programmer.

Applying Models of Computation to OpenCL Pipes for FPGA Computing – Nachiket Kapre and Hiren Patel (University of Waterloo)

We propose imposing a communication discipline inspired from models of computation (e.g.Ptolemy) such as SDF (synchronous dataflow), bulk synchronous (BSP), or Discrete Event (DE). These models offer a restricted subset of communication patterns that enable implementation tradeoffs and deliver performance and resource guarantees. This is useful for OpenCL developers operating within the constraints of the FPGA device. We hope to facilitate a preliminary analysis and evaluation of supporting these patterns in OpenCL and quantifying associated FPGA implementation costs.

Accelerating Applications at Cloud Scale using FPGAs – Sarah Siripoke, Fernando Martinez Vallina and Spenser Gilliland (Xilinx)

The acceptance and success of cloud computing has given application developers access to computing and new customers at a scale never seen below. The inherent ability of an FPGA to reconfigure and be workload optimized is a great advantage given the fast-moving needs of cloud computing applications. In this talk we will discuss how users can develop, accelerate and deploy accelerated applications in the cloud at scale. You will learn how to get started on a turn-key OpenCL development environment in the cloud using Xilinx FPGAs.

Creating High Performance Applications with Intel’s FPGA OpenCL SDK – Andrew Ling, Utku Aydonat, Davor Capalija, Shane O’Connell and Gordon Chiu (Intel)

After decades of research, High-Level Synthesis has finally caught on as a mainstream design technique for FPGAs. However, achieving performance results that are comparable to designing at a hardware description level still remains a challenge. In this talk, we illustrate how we achieve world class performance results on HPC applications by using OpenCL. Specifically, we show how we achieve 1Tflop of performance on a matrix multiply and over 1.3Tflops on a CNN application, run on Intel’s 20nm Arria 10 FPGA device. Finally, we will describe spatial coding techniques that lead to efficient structures, such as systolic-arrays, to ensure that the FPGA runs efficiently.

Symphony – Task Scheduling and Memory Management in Heterogeneous Computing – Amit Jindal and Wenjia Ruan (Qualcomm Technologies)

Task scheduling and memory management are challenges that make Heterogeneous Computing difficult for the masses. There are several programming models and tools that exist targeting partitioning of workload and accessibility of data between CPU and GPU. We have developed and deployed Symphony SDK – a framework that makes workload partitioning, scheduling and memory management ‘simple’ for developers. In this talk, we will introduce Symphony architecture, elaborate how existing OpenCL kernels can be reused with heterogeneous task synchronization, task scheduling, and memory management capabilities of Symphony. We will also share real-world cases where Symphony has provided 2x-6x performance speed-ups.

CUDA-on-CL: A compiler and runtime for running modern CUDA c++11 applications on OpenCL 1.2 devices – Hugh Perkins (ASAPP)

Cuda-on-cl addresses the problem of creating and maintaining OpenCL forks by leaving the reference implementation entirely in NVIDIA CUDA, and writing both a compiler and a runtime component, so that any CUDA c++11 application can in theory be compiled and run directly on any OpenCL 1.2 device. We use Tensorflow framework as a case-study, and demonstrate the ability to run Tensorflow and Eigen kernels directly, with no modification to the original CUDA source-code. Performance studies are also undertaken, and show that the cuda-on-cl program runs at about 25% of the original CUDA-compiled version.

OpenCL in Scientific High Performance Computing—The Good, the Bad, and the Ugly – Matthias Noack (Zuse Institute Berlin)

We present experiences with utilising OpenCL alongside C ++ , MPI, and CMake in two real-world scientific codes. Our targets are a Cray XC40 supercomputer with multi- and many-core (Xeon Phi) CPUs, as well as multiple smaller systems with Nvidia and AMD GPUs. We shed light on practical issues arising in such a scenario, like the interaction between OpenCL and MPI, discuss solutions, and point out current limitations of OpenCL in the domain of scientific HPC from an application developer’s and user’s point of view.

Accelerated Machine Learning Using TensorFlow and SYCL on OpenCL Devices – Andrew Richards, Mehdi Goli and Luke Iwanski (Codeplay)

Codeplay has been working with Google to add SYCL back-end support in TensorFlow, one of the most popular machine learning frameworks, enabling developers to use OpenCL devices with their machine learning applications. SYCL provides an abstraction layer that simplifies parallel development, giving developers access to the computing power of OpenCL devices and reducing the amount of code required. Andrew Richards will talk about how machine learning applications can harness the power of OpenCL using open standards and how, by using SYCL, TensorFlow can be extended to include customized operations running on OpenCL devices.

Analyzing and improving performance portability of OpenCL applications via auto-tuning – James Price and Simon McIntosh-Smith (University of Bristol)

In this talk, we present an approach for analyzing performance portability that exploits that black-box nature of automatic performance tuning techniques. We demonstrate this approach across a diverse range of GPU and CPU architectures for two simple OpenCL applications. We then discuss the potential for auto-tuning to aid the generation of performance portable OpenCL kernels by incorporating multi-objective optimization techniques into the tuning process.

Wavefront Parallel Processing on GPUs with an Application to Video Encoding Algorithms – Biju George and Ben Ashbaugh (Intel)

In this presentation we focus on the application of the wavefront pattern to design efficient GPGPU implementations of video encoding algorithms using OpenCL kernels. We present our experiences in implementing and evaluating four solutions of WPP for inter and intra estimation for AVC on GPUs. We explain the reasoning behind each solution and present the results of our analysis.

Challenges and Opportunities in Native GPU Debugging with OpenCL – Uri Levy (Intel)

In this technical session we’ll present the open architectural design of the debugger and how it fits into the OpenCL JIT compilation flow and the underlying compute technology of the HW with focus on Intel processor graphics. We’ll demonstrate a show case on how to natively work with the debugger to solve functional bugs, as-well-as low-level debugging techniques on SIMD thread level which help to solve complex issues such as misaligned or out of range accesses to local\global memory, stack overflows, Illegal instructions, etc. Finally, we’ll cover the challenges in debugging

Modeling Explicit SIMD Programming with Subgroup Functions – Biju George and Ben Ashbaugh (Intel)

In this presentation, based on our experience in developing publicly released vendor extensions based on subgroups, we explain the advantages of the “explicit SIMD” programming paradigm using OpenCL subgroup and how the subgroups framework can be leveraged to: (1) Model features for performance in OpenCL that are commonly available in programming languages or interfaces based on an “explicit SIMD” programming paradigm such as the AVX intrinsics supported in GCC; and to (2) Model features to expose functionality available in GPU accelerator units that are more conveniently and efficiently exposed using a block API.

StreamComputing is 7 years!

As of 1 April we are 7 years old. Because of all the jokes on that day, this post is a bit later.

Let me take you through our journey how we grew up from a 1-person company to what we’re now. With pride I can say that (with ups and downs) StreamComputing (now rebranded to StreamHPC) has become a brand that equals to (extremely) fast software, HPC, GPUs and OpenCL.

7 years of changes

Different services

After 7 years it’s also time for changes. Initially we solely worked on OpenCL related services, mostly GPUs. And this is what we’re currently doing:

  • HPC GPU computing: OpenCL, CUDA, ROCm.
  • Embedded GPU computing: OpenCL, CUDA, RenderScript, Metal.
  • Networked FPGA programming: OpenCL.
  • GPU-drivers testing and optimisation.
  • Software architecture optimisations.

While you see OpenCL a lot, our expertise in vendor-specific CUDA (NVidia), ROCm (AMD), RenderScript (Google) and Metal (Apple) cannot be ignored. Hence the “Performance Engineers” and not “GPU consultants” or “OpenCL programmers”.

From Fixers to Builders and getting new competition

Another change is that we have been going from fixing code afterwards to building software.

This has been a slow process and had to do with the confidence in performance engineering as an expert profession instead of a trick. We’re seeing new companies coming into the market and providing GPU-computing next to their usual services. This is a sign of the market growing up.

We’re confident in growing further in our market, as we have the expertise to design fast software while the newcomers have gained expertise to write code that runs on the GPU with only little speedup.

Community: OpenCL:PRO to

There have been more times when we wanted to support the community more. The first try was OpenCL:PRO and did not live long, as it was actually unclear to us what “the community” wanted.

In the end it was not that hard. Everybody who starts with OpenCL has the same problems:

  • Lack of convenience code, resulting in many, many wrappers and libraries that are incompatible.
  • Lack of practice projects.
  • Lack of overview on what’s available.

With we aim to solve these problems together with the community. All is shared on Github and anybody can join to complete the information we’ve shared. While our homepage had around 40 pages on these subjects, it was only our personal view on the subjects or had outdated info.

So we’re going to donate most of the OpenCL-related technical pages we’ve written over the years to the community.

There is much more to share – watch our blog, the OpenCLorg twitter and newsletter!

Different Logo

For who remembered: in 2010 the logo looked quite different. We still use the blocks in the background (like on our Twitter account), but since 2014 the colours and font are quite different. This change has been going along with the company growing up. The old logo is careful, while the new one is bold – now we’re more confident about our expertise and value.

Over the past 3 years the new logo has stayed the same and has fully become our identity.

Same kind of customers

It has been quite a journey! We could not have done it without all the customers we served over those 7 years.

Thank you!

Looking for the company’s GPU-pioneers

Getting from the technical advantages to the business advantages we have extensive experience.

Several projects were introduced to us via the company’s GPU-pioneer. These collaborations were very successful and pleasant to do, due to the internal support within the company. This is a reason we would like to do more of these – this text is dedicated to the GPU-pioneers out there.

Seeing the potential of GPUs is not easy, even when you’ve carefully read the 13 types of algorithms that OpenCL can speed up. So it’s even harder to convince your boss that GPUs are the way to go.

Here is where we come in. This is what you need to do. Continue reading “Looking for the company’s GPU-pioneers”

GPUs and Gartner’s Top 10 Strategic Technology Trends For 2017

What brings 2017 in technology? Gartner gives their vision with the start of each year to give insight in which technologies to invest in. When looking through them, the most important enabling technologies are the GPU and Internet-of-Things (IoT) – see the image below. Whereas the last 4 are IoT based, the first 4 would not have been possible without GPUs.

The middle two are more mature technologies, as they’re based on technology progress of many years – it happens to be that the GPU has played a big role to get here. And ofcourse not only GPUs and IoT are the reason these 10 are on this year’s list.

Continue reading “GPUs and Gartner’s Top 10 Strategic Technology Trends For 2017”

When to use Artificial Intelligence and when to use Algorithms?

The main strength of Artificial Intelligence is it’s easy to understand by anybody. This results in new applications in all industries at a rapid pace. Are there new possibilities generated or have the possibilities always been possible? The answer is both.

In case of totally unknown input, AI is better capable of adapting. A clearly defined algorithm has much more unpredictable behavior in such cases.

If the input is known well, the tables are turned. AI could give unpredictable results and with that introducing hard-to-solve bugs. Algorithms do exactly what it is designed for, also often at a much higher performance.

Making the wrong choice here results often in a much more expensive solution. Continue reading “When to use Artificial Intelligence and when to use Algorithms?”
